Mining Metal Detector
Function
Performance Features
Common Applications
Models
Function
Mining Metal Detectors are design for installation on conveyor belts carrying coal, minerals, aggregates, and other bulk materials.
They can be tuned to ignore conductive minerals such as gold, copper or zinc, while still detecting small pieces of trapped metal.
Performance Features
- Field Replaceable, Microprocessor based electronics
- Function, Metal and Fault LED’s
- Automatic test circuits
- Adjustable frequency
- Rugged Fiberglass Reinforced Plastic (FRP) frame and antennas
- Swing Away Transmitter Antenna
- Three year warranty
Common Applications
Aggregates, asphalt and mining, protecting impact crushers and crushers.
Models
Model T-50
Features:
- Field Replaceable, Microprocessor based electronics: Simple to service and maintain with replaceable boards
- Self test circuit with false alarm indicators: Simplified troubleshooting by automatically diagnosing problem
- 32 Digit LED display with bar graph for metal indication: Easy to read and operate
- Function, Metal and Fault LED’s: Always know the status of your metal detector
- EEPROM stored system parameters: System settings can be swapped between electronics, no need to re-program
- Three level password protection: Prevent unauthorized access to key settings and function
- Adjustable Frequency: Airborne interference can be eliminated
- Rugged Fiberglass Reinforced Plastic (FRP) frame and antennas: Able to withstand the harshest environments
- Three year warranty: Ensures long life of reliable service
- Swing Away Transmitter Antenna: Reduces the likelihood of damage from lumps and large over-burdens
- Optional RS232 / RS485 serial link with PC with event log and time stamp: It tracks the performance of the Metal Detector and allows output to a PC for data analysis and archiving.
Model T-5000
Features:
- Field Replaceable, Microprocessor based electronics: Simple to service and maintain with replaceable boards
- Potentiometers for adjusting sensitivity: Easy to operate
- Function, Metal and Fault Indication LED’s: Always know the status of your metal detector
- Self test circuit: Simplified troubleshooting by automatically diagnosing problem
- Adjustable Frequency: Airborne interference can be eliminated
- Rugged Fiberglass Reinforced Plastic (FRP) frame and antennas: Able to withstand the harshest environments
- Swing Away Transmitter Antenna: Reduces the likelihood of damage from lumps and large over-burdens
- Three year warranty: Ensures long life of reliable service
- Flexible design and programming: Adapted to meet unique application requirements
